Lifting the television onto the wall plate should always be handled by two people. Once the hooks on the display arms clear the upper rail of the wall plate, lower the unit gently until the bottom channel seats properly. Secure the bottom locking safety screws immediately to prevent the assembly from jumping off the rail when bumped.
Articulating arms introduce complex rotational mechanics. A wall plate that appears plumb while folded flat against the wall can tilt visibly when extended forward into the room. Factory tolerances on budget mounts allow minor flex within the steel joints.
Check alignment using a dedicated 12-inch magnetic spirit level resting across the top rail of the baseplate during initial anchor tightening. Do not rely entirely on the tiny, snap-in bubble level included inside the Equatech parts bag; these novelty inserts frequently feature misaligned bubble chambers that introduce a 2- to 3-degree slant across a 65-inch screen.
Fine-tune the bracket tilt adjustment via the side friction bolts on each vertical runner. Loosen the hex nuts slightly, tilt the screen forward between 5 and 15 degrees to minimize ceiling light reflections, and torque the nuts firmly back into place before letting go of the display frame.
Finally, dress the interconnect cables with care. When completing an articulating arm installation, run high-speed HDMI and optical cables loosely through each built-in cable management clip along the scissor joints. Keep adequate slack in the wiring near the primary wall hinge. If cables are tied too tightly, pulling the screen out to reach rear ports will pull HDMI connectors sideways, damaging costly circuit boards or snapping internal pin contacts.
